Fogstar 32.2kWh Modular Stack LiFePO4 Battery & Inverter Bundle

Description

The 32.2kWh stack takes a modular approach: two 16.1kWh battery modules sit beneath a dedicated control unit, all inside IP65-rated housings that can live indoors or out. Need more capacity later? Add modules or parallel additional stacks, all the way to 1.23MWh. Your chosen inverter completes the package.

Battery Highlights

• 32.2kWh usable storage from two stacked 16.1kWh modules
• Dedicated control unit with 150A SEPLOS Battery Management System
• IP65-rated for indoor or outdoor installation
• Automatic fire suppression and built-in heating (charges to 0°C, runs to -20°C)
• Up to 300A charge and discharge current
• JK 2A Active Balancer, LCD touchscreen, CAN and RS485 comms
• Integrated 350A breaker for isolation and protection
• Works with Victron, Luxpower, Sunsynk, Solis, Voltronic, Voltacon and more
• Expandable to 1.23MWh; up to 8,000 cycles at 91% depth of discharge
• 6-year warranty with 10 years of UK customer support

Choose Your Inverter

Select the inverter that suits the site:

• 3.6kW Hybrid – a compact single-phase hybrid unit suited to smaller homes, pairing solar input, battery charging and mains backup in one box.
• 10kW Hybrid – a high-output single-phase hybrid for bigger households and light commercial use, with generator input for extra resilience.
• 6kW Off-Grid – a dependable off-grid unit for cabins, workshops and remote buildings with no mains connection.
• 14kW Off-Grid – a heavy-duty off-grid unit for larger properties running entirely without a grid supply.
• 20kW Three Phase Hybrid – a three-phase hybrid designed for commercial premises and homes with a three-phase supply.

Where It Fits

The right platform when you expect demand to grow: farms, commercial units, large homes and scalable off-grid systems that may double in size down the line.
