Description
This package pairs the Solis 8kW or 10kW PLUS single-phase hybrid inverter with the Fogstar Energy modular battery stack, a single integrated battery system of 3 or 4 stacked 16.1kWh modules managed by one top-mounted control unit. Compared with multiple standalone batteries, the modular stack simplifies commissioning, inverter comms and servicing because the inverter sees the whole stack as one battery.
The stack is IP65 rated for indoor, plant room or outdoor installation, has a built-in 350A isolation breaker, integrated heat-activated fire suppression, and self-heating that allows safe charging down to -15°C. That makes it a sensible choice for larger residential systems, workshops, agricultural sites, and small commercial properties where space, safety and serviceability all matter.
Solis PLUS S6 Hybrid Inverter, key features:
- Single-phase low-voltage hybrid, 8kW or 10kW
- 8 MPPTs for flexible solar string design
- Up to 190A maximum charge / discharge current
- Up to 200% DC oversizing for greater solar harvest
- 200% surge power capability for 10 seconds to handle high inrush loads
- Integrated backup port with automatic UPS-level switching for power-cut continuity
- Six fully customisable charge / discharge time slots for tariff optimisation
- AI-optimised cloud-based energy management assistant
- Generator connectivity with automatic start / stop control
- Parallel operation up to 48kW, single or three-phase
- Intelligent AC-coupling for retrofitting to existing solar systems
- Peak shaving in both self-use and generator modes
Fogstar Energy Modular Battery Stack (FE51.2-48.3), key features:
- 51.2V nominal low-voltage LiFePO₄ system
- 48.3kWh per stack (3 × 16.1kWh modules) or 64.4kWh per stack (4 × 16.1kWh modules)
- Single top-mounted control unit manages the whole stack as one battery
- Built-in 350A isolation breaker for full system isolation in maintenance, fault or emergency conditions
- 300A maximum charge and discharge current
- IP65 rated, suitable for indoor, plant room or outdoor wall installation
- Integrated, heat-activated aerosol fire suppression system as standard
- Built-in battery heating allowing safe charging down to -15°C, ideal for UK garages, outbuildings and unheated plant rooms
- JK 2A active cell balancing for long-term cell equalisation
- Heavy-duty base plate, robust sealed enclosure
- Scalable to multiple stacks in parallel, up to 1.23MWh total on the platform
- 6-year manufacturer warranty plus 10 years of UK-based customer support
What you get with this package:
- Solis 8kW or 10kW PLUS hybrid inverter
- Fogstar Energy modular battery stack at your chosen capacity (48.3kWh, 64.4kWh, 96.6kWh or 128.8kWh)
- Grid meter for live energy monitoring
- Full design, supply and installation by our MCS-accredited engineers
- DNO application and G99 / G98 paperwork handled for you
- All cabling, isolators, mounting and commissioning included
- Handover walk-through and app setup on the day
- Installation anywhere in the Midlands included in the price
Why people choose this kit:
- From 48.3kWh up to 128.8kWh of usable storage on a single inverter, ideal for larger residential systems, agricultural sites, workshops and small commercial buildings.
- One integrated battery instead of three or four loose units: cleaner installation, simpler comms, less to maintain.
- IP65 rating means the stack can mount outside on a wall or in an unheated plant room, freeing up indoor space.
- Built-in 350A breaker gives proper isolation for service work without separate external switchgear.
- Fire suppression and -15°C self-heating come as standard, useful for UK winter installs in unheated locations.
- AI optimisation learns your usage and your tariff so the system runs itself after the first week.
- Lithium iron phosphate (LFP) chemistry is safer and longer-cycling than older NMC packs.
- 6-year manufacturer warranty plus 10 years of UK-based support on the battery.
What’s included in the install:
- Site survey and electrical assessment
- Wall or floor mounting of the inverter and battery stack
- AC, DC and comms wiring to your consumer unit
- CT clamp and grid metering for live energy monitoring
- System commissioning and app pairing
- Customer handover and aftercare contact
Coverage: Midlands installation included in the price.
Battery warranty: Fogstar Energy modular stack: 6-year manufacturer warranty plus 10 years of UK-based customer support.
Note: The Fogstar modular battery stack is currently on pre-order with stock expected at the start of June. Order now to reserve your slot in our install schedule.
